| Machine type | BAOC-9DL | BAOC-13DL | BAOC-13DL-2 |
| Wire finished | AL Φ4.8-Φ2.8mm | AL Φ4.8-Φ1.7mm | AL 2*(Φ4.0- Φ1.7mm) |
| AL-alloy Φ4.5-Φ3.2mm | AL-alloy Φ4.5-Φ2.3mm | AL 1*(Φ5.0- Φ1.7mm) | |
| Wine inlet | Φ9.50mm | Φ9.50mm | 2*Φ9.50mm |
| Drawing line speed | 20m/s | 25m/s | 22m/s |
| Drawing dies No. | 9 | 13 | |
| Fix speed capstan dia. | Φ450mm | ||
| Main motor | AL AC 250KW AL-alloy AC 280KW | AC 420 KW | |
| Power of tow motor | AC 75KW | AC 90 KW | |
| Drawing drum | Coated by tungsten | ||
| Drum arrangement | Horizontal type | ||
| Take-up type(optional) | (Double Take-up)、(Coiler)、(WS1000 Spool for wire take up)WS1000 | ||
